DV14307.03 Issue 06 February 2021 Transceivers 6200 Series 131
3.6.3.1 Select Channels
• The functions "LAST" and Store/Restore are only available if they are
enabled in the configuration setup* - ("MEM OPTIONS").
* (Details see "Configuration Setup" page 69).
Example: With CH01 user channel shown on the display:
In order to select the channel number:
…
• The first turn clockwise in channel mode starts access to the user
channels CH01…CH99.
o Make a short push on the rotary encoder or:
o Make one clockwise turn with the rotary encoder.
• The channel number is now highlighted.
• Turn the rotary encoder to select a channel.
• With each step the device tunes immediately to the shown frequency.
o The first turn counter-clockwise starts access to the channel
"LAST 1".
o The channel number is now highlighted.
o One of the nine last used channels is selectable.
o Turn the rotary encoder to select a channel.
• The "LAST" mode is left automatically after a 5 second timeout or stopped
by the user with a push on the rotary encoder.
• When leaving the "LAST" channel database and the last shown frequency
is not stored in the user channel database, the display shows "CH__".
• Push "STO" to start the storage process.
• Push the "MDE" key.
o The channel mode will be closed.
o The standard mode page is shown.
Frequency Storage Functions
Start store function:
• Push "STO" key.
(in "Standard", Direct Tune" or "SCAN Mode").
o The symbol "STO" is shown.
IC
SQ
L
125.875
LAST
TWR EDSB
1
