2.6 Installation and Configuration
The minimum installation for the 62XX series transceivers is:
• Power supply.
• Antenna.
• Microphone (direct or with external audio panel).
• Headphone or speaker (direct or with external audio panel).
• Push-To-Talk (PTT) switch.
General Requirements
• For general instruction e.g. installation distance, cable types etc. please see "Installation
Requirements" page 47.
• Type-specific cable harnesses are also available for the aircraft wiring (see "Accessories",
page 41).
• No RF antenna cables or HF cables should be included in the cable harnesses of the
system.
• Prevent routing of the cable harness along with other wiring, which carry audio power or
pulses.
• Examine the wiring carefully before power up the device(s) and examine
particularly correct connection of the power supply lines.
Customized Applications
Customized applications and wiring and configuration adjustments.
General Aviation (GA) Aircraft
Individual Dual Headset Installation (two IC Circuits)
Twin Seat with AR62XX (Tandem-Installation)
Four Seat Installation (no Tandem)
Installation with RT62X1 and RCU62X1Fehler! Verweisquelle konnte
nicht gefunden werden.
nicht definiert.
Installation in Aircraft with Intercom System
Twin Seat with RT62X1 (Tandem-Installation)Fehler! Verweisquelle
konnte nicht gefunden werden.
nicht definiert.
Antenna Installation
• A distance of ≥ 50 cm from the COM antenna to any installed GPS antenna is necessary
and a distance as far away from any ELT antenna.
• Refer always to the manufacturer's instructions for antenna installation.
• Make the antenna installation in accordance with AC 43.13-2B Chapter 3.
For penetration of the pressurized cabin on a pressurized aircraft are additional
data necessary which are not contained in this installation manual.
