Emergency Operation
Emergency Operation: 9.0…10.25 VDC (decreased performance).
• The display shows "LOW BATT" if the supply voltage is less than the
predefined threshold.
o That is the notice for the user, that he should connect a headset
because the speaker could be turned off soon.
• If the supply voltage is < 10.25 V, the device continues operation with
decreased performance.
o The speaker output of the transceiver is automatically set to "OFF"
without further indication.
o A headset is required to continue operation of the transceiver.
• If the supply voltage is < 9.0 Volt, the device is automatically set to "OFF".
AR62XX, RCU62X1
(Emergency Operation)
Specifications
Panel & Display Backlight
turned off
TX Output Power
≥ 2 W into 50 Ω (with modulation)
TX Modulation Depth
≥ 50%
RX Sensitivity
≤ -93 dBm for a (S+N)/N ratio of 6 dB
Dimensions & Weight
AR62X1
AR62X3
RCU62X1
RT62X1
Front panel
(W x H)
61 x 61 mm
(2.4 x 2.4 inch)
158.8 x 41.2 mm
(6.25 x 1.62 inch)
61 x 61 mm
(2.4 x 2.4 inch)
61 x 61 mm
(2.4 x 2.4 inch)
Device depth
205.7 mm
(8.98 inch)
224.4 mm
(8.83 inch)
65.9 mm
(2.59 inch)
188 mm
(7.4 inch)
Mounting depth
184.8 mm
(7.28 inch)
224.4 mm
(8.83 inch)
39.3 mm
(1.55 inch)
188 mm
(7.4 inch)
Installation
method
Rear panel
Ø58 mm (2¼ inch)
Mounting kit
MK6403-1
panel mount
160 mm (6.3 inch)
Rear panel
Ø58 mm (2¼ inch)
Mounting kit*
MK6201-(010)
Material
AlMg/Plastic
AlMg/Plastic
AlMg/Plastic
AlMg
Surface treatment
Control-head coated with black matt paint
N/A
Weight
675 g (1.488 lbs)
800 g (1.763 lbs)
200 g (0.44 lbs)
600 g (1.32 lbs)
Notice: *Use the installation method with the mounting kit to obey the conditions for certification.
