Installation
Becker Avionics
Dimensions
52
Transceiver
s 6200 Series
DV14307.03 Is
sue 06 Februar
y 2021
RCU62
X1
Dimensions mm (i
nch)
Figure
13
: Dimensi
ons
-
RCU62
X1
"Center of Gravity" i
s without other equi
pment.
Permitted dev
iation for dim
ensions wit
hout tolerances:
DIN ISO 2768 T
1 C (dimensions
in mm)
xx...6 (±0.3)
>30...120 (±0.
8)
>400...1000
(±2.0)
>6...30 (±0.
5)
>120...400 (±1.
2)
>1000...20
00 (±3.0)
CEN
TER OF GR
A
VIT
Y
39.3
(1.55)
61
(2.4)
26 (1.0)
30 (1.2)
61 (2.4)
27 (1.1)
60.2 (2.
37)
65.9 (2.
59)
51
53
