Becker RT6201 - General Aviation (GA) Aircraft

Installation
Becker Avionics
Aircraft Wiring
96 Transceivers 6200 Series DV14307.03 Issue 06 February 2021
General Aviation (GA) Aircraft
2.9.6.1 Configuration - General Aviation Aircraft (with Standard Microphones)
Sub-Menu
Function/Selection
"SPKR VOLUME SOURCE"
BOTH
"CONFIGURATION"
"SWAP MIKE IC" Disabled
"IN/OUT CFG1"
(/MIKE_SW open):
"MICROPHONE 1" STD1_MIKE
"MICROPHONE 2" NONE
"BOTH MIKES" Disabled
"HEADPHONE 1" Enabled
"SPEAKER" Disabled
"IN/OUT CFG2"
(/MIKE_SW closed):
"MICROPHONE 1" STD1_MIKE
"MICROPHONE 2" NONE
"BOTH MIKES" Disabled
"HEADPHONE 1" Enabled
"SPEAKER" Enabled
Remarks:
• The standard microphone input is selected regardless of the
position of the external switch.
The external switch (J1-24 /MIKE_SW) works as follows:
• Open:
o The speaker is disabled.
o Intercom with VOX is possible.
• Closed:
o The speaker is enabled.
o No intercom with VOX is possible.
o The speaker symbol is permanent shown on the display.
