DV14307.03 Issue 06 February 2021 Transceivers 6200 Series 127
3.6 Frequency Selection Modes
Available modes:
• Standard mode
• Direct tune mode
• Channel mode
• Scan mode
• The availability of the modes depends on the adjustments in the
* (Details see "Configuration Setup" page 69).
The modes "Standard Mode", "Direct Tune Mode" and "Channel Mode" have different layouts for the
selection of the operating frequency.
• The modes are selectable with short push of the "MDE" key, one after the other.
o The display shows one by one: "Standard Mode", "Direct Tune Mode" "Channel
Mode", "Standard Mode", and so on.
• During the changes between the modes the active frequency is always the same and
active.
The mode SCAN is a sub-mode of standard mode and is for monitoring two frequencies at the same
time.
• Push "↕/SCN" key (2 s) to start/stop the scan function.
