Installation in Aircraft with Intercom System
2.9.10.1 Configuration - Aircraft with Intercom System
Sub-Menu
Function/Selection
"SPKR VOLUME SOURCE"
BOTH
"CONFIGURATION"
"SWAP MIKE IC" Disabled
"IN/OUT CFG1":
"MICROPHONE 1" STD1_MIKE
"MICROPHONE 2" NONE
"BOTH MIKES" Enabled
"HEADPHONE 1" Enabled
"SPEAKER" Disabled
"IN/OUT FG2"
"MICROPHONE 1" STD1_MIKE
"MICROPHONE 2" NONE
"BOTH MIKES" Enabled
"HEADPHONE 1" Enabled
"SPEAKER" Enabled
Remarks:
Use the same configuration for balanced and unbalanced wiring.
