Variants Overview
DV14307.03 Issue 06 February 2021 Transceivers 6200 Series 21
1.4.2.3 RT62X1 Remote-Controlled Transceiver
• The RT62X1 is a remote-controlled device. It does not include a control panel.
• It can receive commands and supplies data through the RCU62X1 (Remote Control Unit)
or a third-party controller.
• It is made for installation in avionic compartment for general aviation aircraft and
helicopters.
To obey the conditions for certification, use the mounting kit MK6201-(010).
Figure 4: RT6201, RT6211 Remote-Controlled Transceiver
1.4.2.4 RCU62X1 Remote Control Unit
• The RCU62X1 is a compact and lightweight device, made for operation in a cockpit
environment for general aviation aircraft and helicopters.
• All controls and indicators are on the front panel.
The equipment connector is at the rear side of the device.
• Installation with four screws (rear panel installation).
The dimensions agree with the standard instrument diameter of 58 mm (2¼ inch).
Figure 5: RCU6201, RCU6211 Remote Control Unit
