Becker RT6201 User Manual

Becker Avionics
General Description
Order Code
DV14307.03 Issue 06 February 2021 Transceivers 6200 Series 41
Accessories
Qty
Connector Kit
1
CK4201-S (soldering version);
• D-Sub 25-s, Connector housing, Antenna plug, Label
"COMM"
Article-No. 0879.304-954
1
CK4201-C (crimp version);
• D-Sub 25-c, Connector housing, Antenna plug, Label
"COMM"
Article-No. 0514.901-954
1
CK6000-S (soldering version);
• D-Sub Connector LE M 25pol, Connector housing
Article-No. 0640.621-954
1
CK6000-C (crimp version);
• D-Sub Connector LE M 25pol, Connector housing
Article-No. 0640.611-954
1
CK6200-S (soldering version);
• D-Sub 25-s, D-Sub 25-p,2 Connector housings, Antenna
plug, Label "COMM"
Article-No. 0617.903-954
1
CK6200-C (crimp version);
• D-Sub 25-s, D-Sub 25-p,2 Connector housings, Antenna
plug, Label "COMM", Coding key
Article-No. 0617.891-954
1
CK5000-S (soldering version);
• D-Sub 15-s, Connector housing, Label "COMM", Label
"NAV", Label "ADF", Label "XPDR"
Article-No. 0511.791-954
1
CK5000-C (crimp version);
• D-Sub 15-s, Connector housing, Label "COMM", Label
"NAV", Label "ADF", Label "XPDR"
Article-No. 0511.781-954
Qty
Cable Harness
1
1K062 Cable harness AR62XX (open cable ends), length 3.7 m,
for sailplanes, motor gliders, to be used for:
• Headphone
• Dynamic microphone
• Speaker
• PTT switch
• Power supply
Article-No. 0621.390-950
1
1K065 Cable harness AR62XX (prepared with connectors),
length 3.7 m, for general aviation, to be used for:
• 2x Phone, jack socket PJ55
• 2x Standard microphone, jack socket PJ68
• 1x PTT switch
• 1x Audio in, jack socket 3.5 mm
• 1x Power supply
Article-No. 0621.455-950
For details please refer to "Cable Harness", page 111.
Qty
Installation Material
1
Mounting Kit MK6201-(010)
Article-No. 0631.515-261
1
Mounting Kit MK6403-1
• 6x Attachment screws
• 6x Attachment clips
Article-No. 0598.569-284
1
Adapter for AR3201 wiring 1AD042
Article-No. 0877.522-959

Becker RT6201 Specifications

General

Brand	Becker
Model	RT6201
Category	Transceiver
Language	English
