Configuration Setup
74 Transceivers 6200 Series DV14307.03 Issue 06 February 2021
Memory Options
Notice: The menu is available on the primary and secondary controller.
• Two options are available:
• Select the option with the rotary encoder.
• Push the "STO" key to enabled/ disabled it.
• If this option is enabled the user can store frequencies in any of the
99 available channels.
• If this option is disabled the user has access only to stored channels.
STORE LAST CHANNELS:
• If this option is enabled, the device automatically stores the last used
VHF frequency in the "Last Channel" database and the user has
access to these channels.
• If this option is disabled the user has no access to these channels.
Modification, Battery
Notice: The menu is available on the primary and secondary controller.
• Three options are available:
• The options support different user interfaces for the selection of the
operating frequency.
• Select the option with the rotary encoder.
• Push the "STO" key to enabled/disabled it.
• Enables/disables "Standard Mode"
BATTERY VOLTAGE:
• Enables/disables "Direct Tune Mode".
CHANNEL MEMORY:
• Enables/disables "Channel Mode".
• When "BATTERY VOLTAGE" is disabled the "DIRECT TUNE
MODE" page is no longer available in the normal operation.
• Store a frequency in a specific channel is possible even if only
"BATTERY VOLTAGE" or "STANDBY FREQUENCY" is selected.
• It is not possible to disable all options from the "MDE PAGES".
Notice: The menu is available on the primary and secondary controller.
• On this page you can adjust the threshold for indication of the
"LOW BATT" warning page (default adjustment is 10.5 V).
• The low battery threshold depends on battery type.
• The low battery threshold is adjustable.
• Use the rotary encoder for the adjustment.
• The display shows the "LOW BATT" warning if the supply voltage is
less than the "LOW BATT THR" value.
CHANNEL STORE
STORE LAST CHANNELS
MEM OPTIONS
STANDBY FREQUENCY
BATTERY VOLTAGE
CHANNEL MEMORY
MDE PAGES
