Twin Seat Motor Glider
2.9.5.1 Configuration - Twin Seat Motor Glider
Sub-Menu
Function/Selection
"SPKR VOLUME SOURCE"
BOTH
"CONFIGURATION"
"SWAP MIKE IC" Disabled
"IN/OUT CFG1"
(/MIKE_SW open):
"MICROPHONE 1" STD_1 MIKE
"MICROPHONE 2" NONE
"BOTH MIKES" Enabled
"HEADPHONE 1" Enabled
"SPEAKER" Disabled
"IN/OUT CFG2"
(/MIKE_SW closed):
"MICROPHONE 1" NONE
"MICROPHONE 2" DYN_MIKE
"BOTH MIKES" Enabled
"HEADPHONE 1" Enabled
"SPEAKER" Enabled
Remarks:
The external switch (J1-24 /MIKE_SW) works as follows:
• Open:
o Standard microphone is selected.
o The speaker is disabled.
o Intercom with VOX is possible.
• Closed:
o Dynamic microphone is selected.
o The speaker is enabled.
o No Intercom with VOX is possible.
• The speaker symbol is permanent shown on the display.
