Installation
Becker Avionics
Device Assignment
46 Transceivers 6200 Series DV14307.03 Issue 06 February 2021
Type Plate
The device type is specified by the type plate (on the housing):
Example:
Figure 6: Type Plate (example)
Explanation:
PN:
Type designation:
AR6201, AR6211 = Single Block VHF Transceiver 58 mm (2¼ inch)
AR6203, AR6213 = Single Block VHF Transceiver 160 mm (3.6 inch)
RT6201, RT6211 = Remote-Controlled VHF Transceiver
RCU6201, RCU6211 = Remote Control Unit 58 mm (2¼ inch)
Options:
0XX: 8.33/25 kHz channel spacing
1XX: 25 kHz channel spacing only
X1X: 6 W @ 12 V, 10 W @ 28 V
X2X: 6 W @ 12 V
XX2: white illumination color on black panel
SN:
Unique number of the device
AN:
Article number
DoM:
Date of Manufacturing
Software:
Refer to the version on the device type plate
Compliance and Certifications:
Refer to the text and logos on the device type plate
Software/Firmware Status – Functionality
• The software version is shown at the screen for a few seconds after power on
This information is also available with the configuration setup → DEVICE INFO.
• The software versions are subject to change without notice.
