128 Transceivers 6200 Series DV14307.03 Issue 06 February 2021
Standard Mode
• Push the "MDE" key to change to the standard mode page.
o The active frequency is shown in the top line and preset frequency in
the bottom line.
• The change of the active frequency is not possible in standard mode (only
available in direct tune mode).
• The change of the preset frequency is possible.
Change the preset frequency in standard mode:
• Make a "short push" on the rotary encoder to change the MHz digits.
o The changeable digits are shown inverted.
• Turn the rotary encoder clockwise/counter clockwise to change the frequency
in 1 MHz steps.
• Make another "short push" on the rotary encoder to change the 100 kHz digit.
o The changeable digit is shown inverted.
• Turn the rotary encoder clockwise/counter clockwise to change the frequency
in 100 kHz steps.
• Make another "short push" on the rotary encoder to change the 25/8.33 kHz
digits.
o The changeable digits are shown inverted.
• Turn the rotary encoder clockwise/counter clockwise to change the frequency
in 25/8.33 kHz steps.
• A short push of the "↨/SCN" key, exchanges active frequency to preset
frequency and vice versa.
o While the transceiver operates in transmit mode, the exchange
function is disabled.
• Push the "STO" key to store the active frequency into the next vacant memory
position of the user channel database (see "Frequency Storage Functions
",
