Variants Overview
20 Transceivers 6200 Series DV14307.03 Issue 06 February 2021
1.4.2.1 AR62X1 Single Block Transceiver
• The AR62X1 is a single block device made for operation in a cockpit environment for
general aviation aircraft and helicopters.
• All controls and indicators are on the front panel.
The equipment connectors and the antenna socket are at the rear side of the device.
• Installation with four screws (rear panel installation).
The dimensions agree with the standard instrument diameter of 58 mm (2¼ inch).
Figure 2: AR6201, AR6211 Single Block Transceiver
1.4.2.2 AR62X3 Single Block Transceiver
• The AR62X3 is a single block device made for operation in a cockpit environment for
general aviation aircraft and helicopters.
• All controls and indicators are on the front panel.
The equipment connectors and the antenna socket are at the rear side of the device.
• Installation in the cockpit panel of an aircraft with a mounting kit MK6403-1 (see "Mounting
kit - MK6403-1", page 56).
The dimensions agree with the state-of-the-art 160 mm (6.3").
Figure 3: AR6203, AR6213 Single Block Transceiver
