• No audio is available on headphone 2 output, speaker is not
available.
SPEAKER ENABLED:
• Audio is available on speaker (P1-1/P1-14), headphone 2 is not
available.
NONE:
• No audio on headphone 2 output or speaker output.
The IN/OUT CFG2 contains the muting in the way that the "OUTPUTS" are
selected to NONE.
The IN/OUT CFG2 can be set from the user:
Notice: The menu is available on the primary controller.
Notice: "IN/OUT CFG2" is shown only when the MIKE_SW input has active state (J1-24).
When MIKE_SW is connected both configurations CFG1 and CFG2 must be configured.
• On this page you can configure the microphone inputs and
headphone outputs for configuration CFG2.
• Select the option with the rotary encoder.
"MICROPHONE 1" (set only one of the options):
STD1 MIKE:
• Standard microphone input 1 is selected (P1-18/ P1-8).
STD2 MIKE:
• Standard microphone input 2 is selected (P1-9/ P1-8).
STD3 MIKE:
• Standard microphone input 3 is selected (P1-19/ P1-8).
DYN MIKE:
• Dynamic microphone input is selected (P1-6/ P1-5).
NONE:
• No microphone is used in microphone path 1.
"MICROPHONE 2" (set only one of the options):
STD1 MIKE:
• Standard microphone input 1is selected (P1-18/ P1-8).
STD2 MIKE:
• Standard microphone input 2 is selected (P1-9/ P1-8).
STD3 MIKE:
• Standard microphone input 3 is selected (P1-19/ P1-8).
DYN MIKE:
• Dynamic microphone input is selected (P1-6/ P1-5).
NONE:
• No microphone is used in microphone path 2.
"MIC ACTIVATION"
BOTH MIKES ENABLED:
• Input /PTT1 starts transmission from microphone path 1 and 2
(P1-17).
• Input /PTT2 starts transmission from microphone path 2 and 1
(J1-5).
•
Input /IC starts intercom from microphone path 1 and 2 (P1-7).
MICROPHONE 1
○ STD 1 MIKE
○ STD 2 MIKE
○ STD 3 MIKE
● DYN MIKE
○ NONE
MICROPHONE 2
○ STD 1 MIKE
○ STD 2 MIKE
○ STD 3 MIKE
○ DYN MIKE
● NONE
MIC ACTIVATION
BOTH MIKES
OUTPUTS
HEADPHONE 1
○ HEADPHONE 2
○ SPEAKER
● NONE
IN/OUT CFG 2
