Installation
Connector Pin Assignments
DV14307.03 Issue 06 February 2021 Transceivers 6200 Series 61
Headphone(s) Connection
Pin No.
Pin Name
Direction
Function
P1-2
HDPH1_A
OUT
Balanced output for headphone(s) 1
P1-3
HDPH1_B
OUT
Balanced output for headphone(s) 1
P1-20
HDPH2_A
OUT
Balanced output for headphone(s) 2
P1-22
HDPH2_B
OUT
Balanced output for headphone(s) 2
• The headphone 1 output is a balanced, transformer-coupled output providing nominal
300 mW into 75 Ω.
o Use a shielded single wire for headphones requires an unbalanced output
configuration. To get this connect P1-3 to GND.
• The headphone 2 output is a balanced output providing nominal 200 mW into 75 Ω.
• You can connect up to two headphones with phone-impedance of 300 Ω (or higher) in
parallel on each circuit, therefore you can connect up to four headphones at the same
time.
• We also recommend to install the jacks generally isolated from car frame in order to
prevent ground loops.
CAUTION: The headphone 2 output shall be always floating (cannot be connected in
unbalance configuration as headphone 1).
Panel Illumination
Pin No.
Pin Name
Direction
Function
P1-10
ILL_LO
IN
Illumination low input
P1-23
ILL_HI
IN
Illumination high input
• The VHF transceiver supplies illumination for the keys and the display.
• It depends on configuration if the illumination is controlled with front panel or externally.
• It depends on configuration if 14 or 28 V fixed illumination voltage is used or aircraft
dimming-bus voltage is in operation.
o Connect ILL_LO (pin P1-10) to aircraft ground.
o Connect ILL_HI (pin P1-23) to dimming bus.
"Auxiliary" Audio Input
Pin No.
Pin Name
Direction
Function
P1-4
AF_AUX_IN_HI
IN
Auxiliary audio input
P1-21
AF_AUX_IN_LO
-
Auxiliary audio input low
• The AF auxiliary input is used to connect an external audio source (NAV, music-player,
etc.) to the transceiver.
• The external audio is audible only when transceiver is in receive mode.
• The input sensitivity is adjustable in the configuration setup.
• The impedance of this input is 600 Ω.
"LINE_OUT" Audio Output
Pin No.
Pin Name
Direction
Function
P1-14
SPK_LO
-
Speaker ground
P1-15
LINE_OUT_HI
OUT
Linear audio output, unbalanced
• The LINE OUT is used to connect e.g. an external voice recorder to the transceiver.
• The LINE OUT output supplies nominal 1 V
RMS
into 1000 Ω.
