BERTHOLD TECHNOLOGIES LB 480 - Page 210

54733-10BA2L
2 – 210 02.2017
2 Installation Volume 2
Fig. 2-32 Flange shielding with steel cable
Source end piece (inactive)
Shielding head
Steel cable latch, must be latched into
the source end piece
Source end piece with
clutch
Steel cable with
latch for clutch
Latch engaged in clutch
Engage latch in clutch
Steel cable for source positioning
Positioning screw
Clamping screw
Eyebolt
The eyebolts can also be
used as anti-tipping
devices in the assembled
state
Eyebolt
A source type label is
attached on the shielding for
each rod
Source locking mecha-
nism
