SENSseries LB 480 Level measurement
BERTHOLD TECHNOLOGIES GmbH & Co. KG
2 – 213
Volume 2 2 Installation
2
Fig. 2-38 Push the shaft core in
Fix the position with the fixing screw at the head piece.
Attach the covering cap again.
Secure the lock with a padlock or the safety screw.
The source is now installed.
