4.3.2 Installing the Electronics Module
Reassemble the electronics module in reverse order.
Connect the wires between connection head and electronics
correctly.
Check that the wires sit firmly in the terminals.
Replace the O-ring that seals the housing.
Make sure that neither moisture nor metal chips are present in
the connection box.
Carefully insert electronics module with the crystal-multiplier
assembly again into the housing.
Attach the connection head to the detector housing again.
Tighten screws evenly alternating between screws.
Close the housing carefully with the housing cover. To do this,
put the housing cover with the sealing on the housing and
tighten the Allen screws using the specified torque: depending
on the version, M5 with 4 Nm or M8 with 17 Nm (standard val-
ues).
If you have installed a new electronics module:
Place the supplied sticker over the number of the Dev. ID on
the type plate.
Turn on the power supply of the detector again.
Set the software parameters again using the list you have
noted down at the beginning. See also Volume 3 on page 3-
299.
Separate User’s Manuals are available for user interfaces such
as SIMATIC PDM or FOUNDATION
™
Fieldbus.
This completes the replacement of the electronics module.
