SENSseries LB 480 Füllstandsmessung

BERTHOLD TECHNOLOGIES GmbH & Co. KG

2 – 249

Volume 2 5 Technical Information

LB 480

Dimensions in mm

Abmessungen in mm

2.3 Point Detector Installation Examples

Punktdetektor Installationsbeispiele

Application with dip pipe

Anordnung mit Tauchrohr

Application with multipart rod source shielding

Anordnung mit mehrteiliger Stabstrahler-Abschirmung
