BERTHOLD TECHNOLOGIES LB 480

To Next Page

To Previous Page

54733-10BA2L

2 – 268 02.2017

5 Technical Information Volume 2

LB 480

Dimensions in mm

Abmessungen in mm

8.1 Mounting Proposal for Source Shielding LB 744x

Montagevorschlag für Abschirmbehälter LB 744x

~30mm

LB 7440

LB 7445

LB 7442

LB 7446

LB 7444

h90 120 161

Flange Installation

Flanschinstallation

Pedestal Installation

Sockelinstallation

Source Shielding LB 744x

Abschirmbehälter LB 744x
