SENSseries LB 480 Level measurement
BERTHOLD TECHNOLOGIES GmbH & Co. KG
3 – 367
Volume 3 Menu Structure
3
3 Cps Average Mode This item allows you to check whether your calibration is correct.
Enter a count rate and then check the simulated level reading.
To simulate a level reading via a count rate, you have to:
1. Enter a count rate at
Cps Average Mode.
2. Select FIXED VALUE at
Cps Average Test.
IMPORTANT
After the test, do not forget to switch from FIXED VALUE back to
NORMAL; otherwise your measurement signal will remain frozen
at this value.
4 Cps Average Test  Enter the value to be simulated.
To enable the simulation, you must set FIXED VALUE at
Cps
Average Mode
.
5 Cps Comp Average Mode  Only visible when the compensation measurement AUTO GPC
or AUTO PRC is enabled.
Allows you to simulate a count rate for the connected compensation
detector.
To simulate a count rate, you have to:
1. Select FIXED VALUE at Cps Comp Average Test.
2. Enter a count rate at Cps Comp Average Mode.
IMPORTANT
After the test, do not forget to switch from FIXED VALUE back to
NORMAL; otherwise your value for the compensation measure-
ment will remain frozen.
6 Cps Comp Average Test  Only visible when the compensation measurement AUTO GPC
or AUTO PRC is enabled.
Enter the value to be simulated.
To enable the simulation, you must set FIXED VALUE at Cps
Average Mode.
