54733-10BA2L
3 – 368 02.2017
Menu Structure Volume 3
7 Device Temp. Mode Allows you to verify if over- or under-temperature is signaled via the
digital output. Enter a test temperature and then check the signal
at the digital output.
To check the digital output with a test temperature, you have to:
1. Set the digital output via
Digital Out Function to DET. TEMP
(Device Config Setup I/O Setup Digital Output
Digital Out Function, page 3-357).
2. Enter a temperature value in
De v ic e Tem p. Te st.
3. Select FIXED VALUE at
Device Temp. Mode.
After the test, do not forget to switch from FIXED VALUE back to
NORMAL; otherwise the temperature signaling will remain frozen.
8 Device Temp. Test Enter a temperature value in order to test the digital output as
a signal output for over- or under-temperature.
To enable the simulation, you must set FIXED VALUE at
Device Temp. Mode.
