BERTHOLD TECHNOLOGIES LB 480 - Page 76

54733BA26
1 – 76 02.2017
5 Explosion Protection Volume 1
Certificate:
70009819
Project:
70066628
Master Contract:
215040
Date Issued:
2016-
03-07
DQD 507 Rev. 2012-05-22 Page 3
LB 480
-
.
.
-
.
.
-
.
.
-
..-…-.
Version
Description
1
1
Bx
Point Detector 50x50
1
2
Bx
Point Detector 50x50 + Water
1
..
Bx
Point Detector …
2
A
Ax
Rod Detector 500 mm
2
B
Ax
Rod Detector 500 mm + Water
2
..
Ax
..
2
K
Ax
Rod Detector 2000 mm
2
L
Ax
Rod Detector 2000 mm + Water
3
1
Ex
Super-Sens
3
2
Ex
Super-Sens + Water Cooling
3
..
Ex
4
1
Ex
Tower-Sens
4
2
Ex
Tower-Sens + Water Cooling
4
..
Ex
0
0
Without Ex- Type Approval
1
x2
ATEX/IECEx Ex det (passive /
Slave)
2
x2
ATEX/IECEx Ex det (active)
3
x2
ATEX/IECEx Ex deit (passive /
Slave)
4
x2
ATEX/IECEx Ex deit (active)
A
x1
ATEX/IECEx Ex dt (passive /
Slave)
B
x1
ATEX/IECEx Ex dt (active)
C
x1
ATEX/IECEx Ex dit (passive /
Slave)
D
x1
ATEX/IECEx Ex dit (active)
A
Ex-Revision
..
Ex-Revision
..
Signal Output (Slave, HART, etc.)
1
Power Supply: 24 VDC
2
Power Supply: 100 - 240 VAC
Note: in the LB-480 table description above:
d = flameproof
e = increased safety
i = intrinsic safety
t = dust ignition protection by enclosure
