Navigate
The 2194 provides three navigate types: Search Event, Time , History Frame.
16.1 Time Navigate
1. Press the Navigate key on the front panel to enter the NAVIGATE function menu.
2. Press the Type softkey In the NAVIGATE function menu, then select Time.
3. There are two ways to navigate time.
a. Press the Time softkey, then, turn the Universal Knob to select the desired value or press the Universal Knob
then enter the value by the pop keyboard.
b. Press the navigation keys on the front panel to play backward, stop, or play forward in time.
You can press the or keys multiple times to speed up the playback. There are three speed levels: Low
Speed, Medium Speed, and High Speed.
16.2 History Frame Navigate
When the History function is enabled, you can use the navigation controls to play
through the acquired frames.
1. Press the Navigate key on the front panel to enter the NAVIGATE function menu.
2. Press the Type in the Navigate Menu, then select History Frame.
3. Press the Frame Num softkey, then there are two ways to navigate history frames.
a. Turn the Universal Knob to select the desired number or press the Universal Knob then enter the number by
the pop keyboard.
b. Press the navigation keys on the front panel to play backward, stop, or play forward
16.3 Search Event Navigate
When the Search function is enabled and acquisitions are stopped, you can use the navigation controls to go to found
search events
1. Press the Navigate key on the front panel to enter the NAVIGATE function menu.
2. Press the Type in the NAVIGATE function menu, then select Search Event.
3. There are two ways to navigate search events.
a. Press Event Num softkey, then, turn the Universal Knob to select the desired value or press the Universal
Knob then enter the value by the pop keyboard.
b. Press the Navigate keys on the front panel to go to the previous or next search event.
