Math
The oscilloscope supports many math operations between analog channels including addition (+), subtraction (-),
multiplication (*), division (/), FFT, dierential (d/dt), integral (
∫
𝑑𝑡), square root (√). The resulting math
waveform is displayed in white and labeled with “M”. You can use cursors to measure it.
Note:
If the analog channel or the math function is cut o (waveforms do not display on the screen completely), the resulting
math will also be cut o.
9.1 Units for Math Waveforms
Use the channel function menu to set the unit of each channel to “V” or “A”.
The oscilloscope math operation includes units as below:
Math Operation Unit
Addition (+)or subtraction (-) V, A
multiplication (*) 𝑉
2
, 𝐴
2
𝑜𝑟𝑊
division (/) None, 𝑉 ∗𝐴
−1
𝑜𝑟 𝑉
−1
∗𝐴
FFT dBVrms, Vrms, dBm, dBArms, Arms
dierential (d/dt) 𝑉 ∗ 𝑆
−1
𝑜𝑟 𝐴 ∗ 𝑆
−1
integral (dt) VS or AS (V * second or A * second)
square root ( ) 𝑉
1/2
𝑜𝑟 𝐴
1/2
Table 9.1 Math Operations Units
