Operating your ATEM Switcher
3 Adjust the key parameters in the LCD menu if required.
4 Press the 'auto' button to perform the transition as an auto transition, or use the
transition slider for a manual transition.
To perform a graphic transition on the software control panel:
1 Select the DVE transition style button in the transition control block.
If the DVE is being used in an upstream key, the DVE transition style button will be
unavailable for selection until the key is taken off air and off next transition. Refer to
'sharing DVE resources' later in this section for more information.
2 Expand the transition palette and select the DVE transition type. Use the previous
or next arrows to select a different DVE type. The 'effects' graphic wipe icon will be
enabled by default.
3 Select the fill source and key source for the graphic from the drop down list.
4 Adjust the key parameters if required.
5 Perform the transition as an auto transition or manual transition from the transition
control block.
Description of graphic wipe parameters
Rate
Rate specifies the length of the transition in seconds and frames.
The rate can be adjusted using the rate knob or by entering a number on the
number pad and pressing the set rate button.
Direction
The normal direction moves the graphic from left to right, and the reverse direction
changes the direction so that it moves the graphic from right to left.
FlipFlop
When FlipFlop mode is toggled on, the transition changes between normal and
reverse every time the transition is executed. The ‘Normal’ or ‘Reverse’ direction
settings indicates the direction of the next transition.
Fill Source
The fill signal is the graphic used to move across the top of the transition.
Enable Key
Enables or disables the key. Set to ‘on’ to enable, or ‘off’ to disable.
Key Source
The key signal is a grayscale image that defines the region in the graphic that will be
removed so that the fill signal can be correctly stacked on top of the wipe.
TIP Typically, for a graphic transition, the source would normally be a graphic
loaded in a media player. By default, when you select a media player for the fill
source, the key source will automatically select the media player key channel
and set pre multiplied key to 'on'. This means a graphic with a key matte
embedded in the alpha channel will automatically be selected by the switcher.
You can disable pre multiplied key and change the key source if you want to use
a separate media file on a different media player, or a different input source.
121
