Blackmagicdesign ATEM - MIX Transitions

Performing Transitions using ExternalHardwarePanels
Stinger and Graphic Wipe are special transitions which will be covered in a later section.
Mix,dip, wipe and DVE transitions are performed as an auto transition or manual transition
using the transition control block.
On the ATEM 1 M/E Advanced Panel the transition types, for example dip, mix
and wipe, have their own independent selectionbutton. ATEM broadcast
panels share transition types for each button, and the shared transition type is
accessed by holding down the shift button and pressing the transition button.
Mix Transitions
A mix is a gradual transition from one source to another and is achieved by interpolating
gradually between two sources, effectively overlapping the sources for the duration of the effect.
The length of the transition or length of the overlap can be adjusted by changing the mix rate.
Program output for a mix transition.
To perform a mix transition on the ATEM 1 M/E Advanced Panel:
1 On the preview bus, select the video source that you want on the program output.
2 Press the MIX button to select the mix transition type. The LCD menu will automatically
display the transition settings.
3 In the transition settings, use the corresponding LCD control knob to adjust the mix
rate. You can also enter a rate duration using the number pad.
4 Perform the transition as an auto transition or manual transition from the transition
control block.
Press the ‘mix’ button and set the transition rate using the LCD menu
