HyperDeck Control
HyperDeck Setup with ATEMBroadcast Panels
Please follow the steps in this section to set up your HyperDeck with an ATEM Broadcast Panel.
System Control on ATEM 1 M/E Broadcast Panel (top) and
ATEM 2 M/E Broadcast Panel (bottom)
1 Press the ‘HyperDeck setup’ soft button to access the HyperDeck setup menu.
To access the HyperDeck setup menu press the ‘hyper
deck setup’ button in the system control setup menu.
2 Press one of the four numbered ‘HyperDeck’ soft buttons along the top row of the
HyperDeck setup menu to specify which HyperDeck you are setting up.
3 Press the ‘Input’ soft button to let your broadcast panel know that you are about to
specify which source corresponds to your HyperDeck.
