Connecting to a Network
Changing the IP Location on an ATEM Broadcast Panel
1 When there is no communication with the switcher, the NETWRK SETUP menu will
appear on the broadcast panel system control. Select the NETWRK SETUP menu button.
2 Select the SWITCHR IP menu button and use the knobs or the numeric keypad to edit
each field as required.
3 When a field is changed, SAVE and REVERT menu buttons become available. Select
SAVE to save the changed IP address, or REVERT to ignore the changes and revert to
the currently stored IP address.
4 If the switcher IP address setting is changed, selecting SAVE will apply the changes
and the broadcast panel will attempt to establish communication with the switcher
using the new IP address.
Control panel connected OK
Control panel not connected
Changing the Hardware Panel Network Settings
Because the hardware panel is also on the network and communicating with the switcher,
it also has network settings so it can connect to the network. These settings are different to the
switcher IP address, which is just where the panel is looking to find the switcher. The panel
network settings can be changed by following the steps below:
NOTE Changing the switcher IP address on your panel does not change the IP address
of the switcher itself. It just changes where the control panel is looking to find the
switcher. If the control panel cannot find the switcher, then you might need to check the
switcher to see if it’s been set correctly. To change the IP address of the switcher,
connect the switcher via USB to a computer and run Blackmagic ATEM Setup as
described previously in this manual.
Home Menu
ATEM 1 M/E Production Switcher
Pa ne l IP Ad d re ss: 192.168.10.10
Connecting to 192.168.10.240...
