BMW C1 200 - Replacing BMS Control Unit

13.7
Replacing injection nozzle holder
–Open the seat
a
....................................................See Group 52
– Release front guard plate from frame and fold
forward
d
Warning:
Comply with safety precautions when handling or
working with fuel; note that the fuel lines are pressu-
rised!
•
Use hose clamps,
BMW No. 13 3 010
, to close
off fuel hoses (arrows)
•
Use pliers,
BMW No. 17 5 500,
to release hose
clamps
•
Disconnect the fuel hoses
•
Release injector attachments (1, 2)
•
Remove injection nozzle holder by pulling up
When installing:
•
Installation is the reverse of the removal proce-
dure
X
Torque specification:
Injector attachment
(+ Loctite 243) ................................................ 4 Nm
13 61 025
Replacing BMS control unit
–Open the seat
– Remove the backrest
a
....................................................See Group 52
– Remove the rear storage compartment
a
....................................................See Group 46
•
Undo the plug-in connection (arrow) by pulling
the red retainer up whilst simultaneously pulling
the plug to the right
•
Remove fasteners (arrows) securing the BMS
control unit
•
Remove the BMS control unit
When installing:
•
Installation is the reverse of the removal proce-
dure
X
Torque specification:
BMS control unit mount ................................. 5 Nm
13 3 010
C1130110
13 3 010
17 5 500
1
2
C1120050
C1120040
