65.11
Fun audio system
Volume control replacement
– Remove instrument trim
a
....................................................See Group 46
•
Open cable ties (arrows)
•
Disconnect plug (1)
•
Open cable tie (arrow)
•
Remove fastener (1)
•
Slide controller forward and remove together
with wiring harness
When installing:
•
While installation is basically a reversal of the re-
moval process, careful attention should be di-
rected toward the following:
e
Attention:
When installing take pains to ensure that all wiring is
routed correctly! Position to avoid potential rubbing
and abrasion!
X
Torque specification:
Volume control attachment .....................hand-tight
C1650150
1
C1650140
1
