BMW C1 200 - Seat Lock Replacement; Seat Lock Bowden Cable Removal and Intallation

52.5
51 25 252
Seat lock replacement
– Open the seat (
a
52.3)
•
Unclip retainer (4)
•
Detach Bowden cable (3)
•
Remove fasteners (1, 2)
When installing:
•
Installation is the reverse of the removal proce-
dure
X
Torque specification:
Seat lock mount ............................................. 9 Nm
Adjustment data:
Seat lock ..................................................... no play
Seat lock Bowden cable removal and
intallation
– Open the seat (
a
52.3)
– Remove rear left side panel
a
....................................................See Group 46
•
Unclip retainer (2)
•
Detach Bowden cable (1)
•
Remove fastener (arrow) securing cover of seat
lock
C1510020
4
21
3
C1510025
2
1
C1510040
