00.10
Mirror bracket to frame Nm 5
Mirror to mirror bracket Nm 4
Cover on mirror arm Nm 3
Model C1
Connection
52 Seats
Seat to frame Nm 21
Seat lock Nm 9
Backrest Nm Hand-tight
Head restraint to frame Nm 21
Model C1
Connection
61 Electrical equipment
Combination switch Nm 4
Battery cable to battery Nm 3
Battery cable to starter relay Nm 3
Control current cables to starter relay Nm 0,4
Voltage regulator to frame Nm 12
BMS control unit to frame Nm 5
Wipe/wash sensor to frame Nm 3
Earth cable to frame Nm 5
Wiper arms Nm 9
Clamp, cable harness to frame Nm 5
Horn to frame Nm 8
Windscreen wiper motor to bracket Nm 5
Wiper motor bracket to roof frame Nm 5
Stationary shaft, wiper motor Nm 9
Cable to starter Nm 5
Bracket of starter relay to frame Nm 5
Bracket of wiring harness to frame Nm 5
Model C1
Connection
51 Equipment
