00.58
When installing:
•
While installation is basically a reversal of the re-
moval process, careful attention should be di-
rected toward the following operations:
•
Do not lubricate drive variator during assembly or
installation -
do not
grease
•
Check action of transfer element
X
Torque specification:
Drive variator mount
(+ LOCTITE 243)........................................... 60 Nm
Variator cover............................................... 10 Nm
Vent cover...................................................... 9 Nm
Replacing complete drive variator
(Inspection II) every 22,500 km (13,500 miles
)
–
lubricated version only
L
Note:
The nut is secured with thread-locking compound!
•
Use retainer
BMW No. 11 7 521
to undo outside
plate, then remove drive variator with spacer
•
Clean locking compound from crankshaft
threads
•
Clean housing and variator cover
C1000490
11 7 521
C1000291
C1000300
