00.8
Model C1
Connection
36 Wheels
Stub axle, locking fluid Nm 30
Quick-release axle clamp screws Nm 21
Brake caliper at telescopic tube Nm 41
6-point nut to final-drive shaft (rear wheel),
use only once
Nm 130
Auxiliary swing arm to brake caliper holder,
locking fluid, M10
Nm 60 LOCTITE 243
Auxiliary swing arm to powertrain cradle, M8 Nm 21
Spring strut at bottom Nm 21
Model C1
Connection
46 Frame
Body panels to body panels Nm 2,8
Body panels to frame Nm 2,8
Lightweight foam element to frame Nm 5
Foam part to cross member Nm 5
Air plenum to rear wheel mudguard Nm 12
Roof/windscreen to cross bar Nm 5
Windscreen to bracket Nm 5
Bracket, wiper motor to roof frame Nm 5
Rear mudguard to powertrain cradle Nm 12
Air filter housing to powertrain cradle Nm 12
Crash element shoulder bar to frame Nm 9
Holder, crash element to frame Nm 9
Rear frame to frame Nm 21
Suspension strut to rear frame Nm 41
Joint
Nut to frame, front left, M28 Nm 105
Screw to frame, front left, M28 Stage 1 20
Screw to frame, front left, M28 Stage 2 Back off 1/2 turn
Screw to frame, front right Nm 73
Rubber bush to frame Nm 42
Rubber bush to joint Nm 42
Powertrain cradle to joint Nm 73
Joint swinging arms to each other Nm 73
Easy-lift mechanism
Spring strut to leading link Nm 41
Articulated-lever mechanism to frame Nm 21
