How to use this manual
Each chapter starts with a table of contents.
Following the table of contents is a table containing the techical data and specifications for the chapter's
subject.
Chapter 00 describes maintenance procedures and provides general information as well as the pre-delivery
inspection; it furnishes all torque specifications along with listings of fluids and lubricants.
Explanation of symbols
This repair manual for the C1 employs the following symbols; please refer to the table for their meanings.
Special notices for more efficient procedures
L
Note:
These special notices help technicians work more efficiently when operating, inspecting, adjusting and
maintaining motorcycles.
e
Attention:
Special information and precautionary notices to prevent damage to the motorcycle. Failure to observe
these mandatory precautions may invalidate the warranty.
d
Warning:
Precautions intended to protect the rider and/or other individuals against injury as well as potentially fatal
hazards.
Contents
The titles of the operations described in this chapter ............. together with the page numbers
Operations
•
Operations
•
A dot or period identifies individual procedures described under a title
– Previous operations
– The hyphen identifies procedures described in more detail under a different title or in another chapter
Remove means:
to completely unscrew a retaining component (such as a bolt or screw)
or
to detach a component (such as an injection rail) and move it enough to gain access to assemblies installed
behind it (such as a throttle-valve).
Loosen means:
to unscrew an attachment (such as a bolt or screw) without removing it entirely from its threaded socket or
retainer
X
Torque specifications:
These data are indicated whenever torques deviate from the standards defined in DIN EN 24 014 and
DIN 912 ISO.
