11.4
Crank assembly with conrod
Main bearing bore diameter
Installed dimension mm (in)
Wear limit mm (in) 32.07 (1.2626)
Crankshaft - main bearing play
Installed dimension mm (in) 0.030…0.070 (0.001…0.002)
Wear limit mm (in) 0.10 (0.0039)
Main bearing diameter mm (in) 32.015…32.025 (1.2604…1.2608)
Wear limit mm (in) 32.01 (1.2602)
Runout mm (in) 0.07 (0.0028)
Runout at crankshaft journal
Clutch end mm (in) 0.05 (0.0020)
Reluctor end mm (in) 0.05 (0.0020)
Runout connecting rod
Big-end bore mm (in) 0.016…0.060 (0.0006…0.0024)
Wear limit mm (in) 0.07 (0.0028)
Small-end bore mm (in) 0.03 (0.0012)
Connecting rod axial float between
crank webs
mm (in) 0.8 (0.0315)
Axial float at connecting rod bearing
Installed dimension mm (in) 0.25…0.33 (0.009…0.012)
Wear limit mm (in) 0.80 (0.0315)
Runout at connecting rod bearing
Installed dimension mm (in) 0.016…0.060 (0.0006…0.0024)
Wear limit mm (in) 0.07 (0.0028)
Inside Ø of wristpin end bush
Installed dimension mm (in) 15.003…15.008 (0.5907…0.5909)
Wear limit mm (in) 15.03 (0.5917)
Crankshaft axial float mm (in) 0.2…0.4 (0.007…0.015)
Cylinder head
Max. surface irregularity mm (in) 0.05 (0.0019)
Camshaft journals I/E mm (in) 17.969…17.980 (0.7079…0.7078)
Wear limit mm (in) 17.96 (0.707)
Camshaft
Camshaft bearing bridge I/E mm (in) 18.02…18.04 (0.709…0.710)
Wear limit mm (in) 18.07 (0.711)
Bearing width mm (in) 23.8…23.9 (0.93…0.94)
Wear limit mm (in) 23.7 (0.93)
Technical Data C1 C1 200
