11.8
Direction of installation Arrow on piston crown points toward exhaust
Cylinders
Bore
Cylinder “A” mm (in) 56.388…56.398
(2.2200…2.22204)
61.988…61.997
(2.4404…2.4408)
Cylinder “B” mm (in) 56.402…56.412
(2.2206…2.2209)
62.003…62.012
(2.4411…2.4414)
Timing chain
Distance from sealing face to chain tensioner plunger
Wear limit mm (in) 6 (0.2362)
Water pump
Water-pump shaft bearing in housing mm (in) 10.05…10.07 (0.395…0.396)
Wear limit mm (in) 10.08 (0.3968)
Oil pump
Oil-pump gear
Axial run-out mm (in) 0.3 (0.0118)
Oil-pump shaft outside diameter mm (in) 7.972…7.987 (0.3139…0.3145)
Wear limit mm (in) 7.96 (0.3134)
Wear limit in housing mm (in) 8.03 (0.3161)
Technical Data C1 C1 200
