11.13
•
Remove lines from clips:
–Injector
– Air temperature sensor
– Idle actuator
– Coolant temperature sensor to cylinder head
•
Release coolant hose from clip at injector and
bracket (arrow) on variator cover
•
Remove hose from bracket at intake-air plenum
chamber (arrow)
•
Position vehicle hoist,
BMW No. 00 1 570,
with
attachment
BMW No. 00 1 580,
at separation
point
•
Slightly raise vehicle with lifter
•
Install fitting,
BMW No. 33 1 531,
between left
spring strut and powertrain cradle
•
Remove lower end of spring strut at brake caliper
bracket
e
Attention:
To avoid overstretching hoses and wiring do not
swivel powertrain cradle more than max. 20°!
•
Lift C1 no further than travel stop: powertrain
cradle swivels down
C1000110
C1000120
C1000130
C1000140
00 1 570
33 1 531
00 1 580
