Item Specified
value
Unit of measure or
specification
Oil capacities
Engine (with filter)
Gearbox
1.0 (0.22)
0.090 (0.020)
litres (Imp pints)
15W40
litres (Imp pints)
API GL 4
Coolant
Cooling system
Expansion tank
1.25 (2.2)
0.2 (0.35)
litres (Imp pints)
litres (Imp pints)
Mixing ratio:
Water: 50%
Antifreeze: 50%
Protection down to
–25 °C (-13 °F)
Windshield washer fluid
1.0 (1.8) litres (Imp pints)
Water and cleaning prod-
uct, antifreeze as required
Brake fluid
DOT 4
Valve clearances
Measured cold, maximum 35 °C (95 °F)
Inlet: 0.05…0.14
(0.002…0.006)
Exhaust: 0.20…0.29
(0.009…0.010)
mm
(in)
mm
(in)
Spark plugs
Electrode gap 0.8…0.9
(0.031…0.035)
NGK CR8 EB
mm
(in)
Idle speed
1900 rpm
Tyre pressures (tyres cold)
Solo
Full load
Front/rear
1.9/2.1 (27.6/30.5)
1.9/2.4 (27.6/34.8)
bar (psi)
bar (psi)
Tightening torques:
Engine oil drain plug
Oil strainer to engine
Engine water drain plug
Oil filter cover
Camshaft gears to camshaft
Guide rail to camshaft support
Chain tensioner plug
Camshaft bearing bridge
Valve cover
Machine bolt TDC setting
Spark plug
Driving variator
Driving variator cover
Driven variator
Locknut of clutch to driven variator
Variator cover to power train link
Ventilation cover for variator
Front stub axle
Clamping bolts for front stub axle
Brake calliper at fork slider tube
Bleed screw in brake calliper
Cover of handbrake control
Rear stub axle,
use nut only once
Exhaust to cylinder head
Auxiliary link to power train link M8
Auxiliary link to power train link M10
Silencer to auxiliary link
Suspension strut to power train link/brake calliper holder
Link mounting to power train link
Tubular link to frame
Stand to frame
Rubber element to tubular link
Cladding bolts
20
30
10
10
30
10
35
10
10
15
15
60
4
60
50
10
9
30
21
41
14
Hand-tight
130
15
21
60
21
21
73
73
41
42
2.8
Nm
Nm
Nm
Nm
Nm (Loctite 243)
Nm (Loctite 243)
Nm
Nm
Nm
Nm
Nm
Nm (Loctite 243)
Nm
Nm
Nm (Loctite 243)
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm
Nm (Loctite 243)
Nm
Nm
Nm
Nm
Nm
Nm
Nm
