Bosch BAT 690 - Maintenance and Cleaning; Decommissioning and Disposal; Technical Data Specifications

1 689 989 234 2018-06-08| Robert Bosch GmbH
Maintenance | BAT 690 | 23 en
¶ Disconnect BAT 690 from the mains voltage system.
7.2 Spare and wearing parts
Designation Order number
Power supply cable 3 m
<)
1 684 461 195
Red/black charging cable set (3m; 16mm
2
)
<)
1 687 011 533
Red/black charging cable set (5m; 16mm
2
)
<)
1 687 011 535
Wall mounting 1 688 005 254
<)
Wearing part
9. Technical Data
Property Value, range
Maximum charging current 90 A
Length of charging cable 3 m / 9.8 ft
Charging cable cross-section 16 mm
2
Max. power consumption 1600 W
Weight (without accessories) 6.6 kg / 14.6 lb
Charging characteristic of universal
battery
I1U1I2aI3aI3...
Charging cut-off voltage U2 for
universal battery (temperature-
regulated)
12V
24V
14,2 V – 14,8 V
28,4 V – 29,6 V
Back-up mode 12V
Back-up mode 24V
11 V – 14,2 V / 3 A - 30 A
22 V – 28,4 V /3 A - 22 A
Buffer mode 12V
Buffer mode 24V
11 V – 14,2 V / 3 A - 90 A
22 V – 28,4 V / 3 A - 45 A
Function temperature range -5 °C – 45 °C
Storage temperature range
Transport temperature range
-25 °C – 60 °C
Mains voltage
Mains frequency (230V)
230 VAC +6%/-10%
50 Hz / 60 Hz ±4%
Rated battery voltage 12 V / 24 V
Protection class (EN 60529:1991 +
A1:2000 + A2:2013)
IP 20D
Protection class
(EN 61140:2002 + A1:2006)
I
Dimensions (W x H x D)
Dimensions (W x H x D) (USA)
220 x 116 x 473 mm
8.7 x 4.6 x 18.6 inch
Workplace-related
noise emission value (Lpa)
(with fan on)
< 60 dB(A)
7. Maintenance
! Work on electrical equipment is only to be
performed by persons with sufficient knowledge and
experience of electrical systems!
7.1 Cleaning
!
Do not use abrasive cleaning agents and coarse
workshop cloths!
¶ The housing and the LCD are only to be cleaned
using a soft cloth and neutral cleaning agents.
8. Decommissioning
8.1 Temporary shutdown
In the event of lengthy periods of non-use:
8.2 Change of location
¶ If the BAT 690 is passed on, all the documentation
included in the scope of delivery must be handed over
together with the unit.
¶ The BAT 690 is only ever to be transported in the
original or equivalent packaging.
¶ Unplug the electrical connection.
¶ Heed the notes on initial commissioning.
8.3 Disposal and scrapping
BAT 690, accessories and packaging should
be sorted for environmental-friendly recycling.
¶ Do not dispose BAT 690 into household
waste.
Only for EC countries:
The BAT 690 is subject to the European
directive 2012/19/EC (WEEE).
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
¶ Make use of the local return and collection
systems for disposal.
¶ Proper disposal of BAT 690 prevents
environmental pollution and possible health
hazards.
1. Disconnect the BAT 690 from the mains and detach
the power cord.
2. Dismantle the BAT 690 and sort out and dispose
of the different materials in accordance with the
applicable regulations.
