The scope area-id parameter displays detailed information about the LSAs for a specied area, AS, or link.
TABLE 71 show ipv6 ospf database output descriptions
This eld Displays
Area ID The OSPF area in which the device resides.
Type Type of LSA. LSA types can be the following:
• Rtr - Router LSAs (Type 1).
• Net - Network LSAs (Type 2).
• Inap - Inter-area prex LSAs for ABRs (Type 3).
• Inar - Inter-area router LSAs for ASBRs (Type 4).
• Extn - AS external LSAs (Type 5).
• Link - Link LSAs (Type 8).
• Iap - Intra-area prex LSAs (Type 9).
LS ID The ID of LSA in Decimal.
Adv Rtr The device that advertised the route.
Seq(Hex) The sequence number of the LSA. The OSPF neighbor that sent the LSA stamps it with a
sequence number to enable the device and other OSPF routers to determine which LSA for a
given route is the most recent.
Age The age of the LSA, in seconds.
Chksum A checksum for the LSA packet. The checksum is based on all the elds in the packet except the
age eld. The device uses the checksum to verify that the packet is not corrupted.
Len The length, in bytes, of the LSA.
Sync Sync status with the slave management processor (MP).
To display the show ipv6 ospf database advr command output, enter the following command at any CLI level.
device# show ipv6 ospf database advr 192.168.98.111
LSA Key - Rtr:Router Net:Network Inap:InterPrefix Inar:InterRouter
Extn:ASExternal Grp:GroupMembership Typ7:Type7 Link:Link
Iap:IntraPrefix Grc:Grace
Area ID Type LSID Adv Rtr Seq(Hex) Age Cksum Len Sync
0.0.0.200 Link 136 192.168.98.111 80000007 634 fb0b 64 Yes
Router Priority: 1
Options: V6E---R--
LinkLocal Address: fe80::768e:f8ff:fe3e:1800
Number of Prefix: 1
Prefix Options:
Prefix: 5100::193:213:111:0/112
To display the show ipv6 ospf database as-external command output, enter the following command at any CLI level.
device# show ipv6 ospf database as-external
LSA Key - Rtr:Router Net:Network Inap:InterPrefix Inar:InterRouter
Extn:ASExternal Grp:GroupMembership Typ7:Type7 Link:Link
Iap:IntraPrefix Grc:Grace
Area ID Type LSID Adv Rtr Seq(Hex) Age Cksum Len Sync
N/A Extn 2 192.168.98.213 80000004 895 6e5e 44 Yes
Bits: E--
Metric: 0
Prefix Options:
Referenced LSType: 0
Prefix: 5100:213:213:0:192:213:1:0/112
LSA Key - Rtr:Router Net:Network Inap:InterPrefix Inar:InterRouter
Extn:ASExternal Grp:GroupMembership Typ7:Type7 Link:Link
Iap:IntraPrefix Grc:Grace
Area ID Type LSID Adv Rtr Seq(Hex) Age Cksum Len Sync
N/A Extn 1 192.168.98.190 80001394 643 1cc9 28 Yes
Bits: E--
Metric: 1
Displaying OSPFv3 information
FastIron Ethernet Switch Layer 3 Routing
322 53-1003627-04
