TABLE 95 show ip bgp neighbors route-summary output descriptions (continued)
This eld Displays
• AS Loop - An AS loop occurred. An AS loop occurs when the
BGP4 AS-path attribute contains the local AS number.
• maxas-limit aspath - The number of route entries discarded
because the AS path exceeded the congured maximum length
or exceeded the internal memory limits.
• Invalid Nexthop - The next-hop value was not acceptable.
• Duplicated Originator_ID - The originator ID was the same as
the local device ID.
• Cluster_ID - The cluster list contained the local cluster ID, or the
local device ID if the cluster ID is not congured.
Routes Advertised The number of routes the device has advertised to this neighbor:
• To be Sent - The number of routes queued to send to this
neighbor.
• To be Withdrawn - The number of NLRIs for withdrawing routes
the device has queued to send to this neighbor in UPDATE
messages.
NLRIs Sent in Update Message The number of NLRIs for new routes the device has sent to this
neighbor in UPDATE messages:
• Withdraws - Number of routes the device has sent to the
neighbor to withdraw.
• Replacements - Number of routes the device has sent to the
neighbor to replace routes the neighbor already has.
Peer Out of Memory Count for Statistics for the times the device has run out of BGP4 memory for
the neighbor during the current BGP4 session:
• Receiving Update Messages - The number of times UPDATE
messages were discarded because there was no memory for
attribute entries.
• Accepting Routes (NLRI) - The number of NLRIs discarded
because there was no memory for NLRI entries. This count is
not included in the Receiving Update Messages count.
• Attributes - The number of times there was no memory for
BGP4 attribute entries.
• Outbound Routes (RIB-out) - The number of times there was
no memory to place a "best" route into the neighbor route
information base (Adj-RIB-Out) for routes to be advertised.
Displaying BGP4 neighbor information
You can display
conguration information and statistics for BGP4 neighbors of the device.
To view BGP4 neighbor information, including the values for all the congured parameters, enter the following command.
NOTE
The display shows all the congured parameters for the neighbor. Only the parameters that have values dierent from their
defaults are shown.
device(config-bgp)# show ip bgp neighbors 10.4.0.2
Total number of BGP neighbors:
1 IP Address: 10.4.0.2, AS: 5 (EBGP), RouterID: 10.0.0.1
Description: neighbor 10.4.0.2
Local AS: 101
State: ESTABLISHED, Time: 0h1m0s, KeepAliveTime: 0, HoldTime: 0
PeerGroup: pg1
Multihop-EBGP: yes, ttl: 1
Displaying BGP4 information
FastIron Ethernet Switch Layer 3 Routing
53-1003627-04 443
