Prefix Options:
Referenced LSType: 0
Prefix: ::/0
LSA Key - Rtr:Router Net:Network Inap:InterPrefix Inar:InterRouter
Extn:ASExternal Grp:GroupMembership Typ7:Type7 Link:Link
Iap:IntraPrefix Grc:Grace
Area ID Type LSID Adv Rtr Seq(Hex) Age Cksum Len Sync
N/A Extn 2 192.168.98.71 80000258 132 a3ff 32 Yes
Bits: E-T
Metric: 1
Prefix Options:
Referenced LSType: 0
Prefix: ::/0
Tag: 1
To display detailed information about all LSAs in the database, enter the following command at any CLI level.
device# show ipv6 ospf database extensive
LSA Key - Rtr:Router Net:Network Inap:InterPrefix Inar:InterRouter
Extn:ASExternal Grp:GroupMembership Typ7:Type7 Link:Link
Iap:IntraPrefix Grc:Grace
Area ID Type LS ID Adv Rtr Seq(Hex) Age Cksum Len Sync
0.0.0.200 Link 897 192.168.98.213 80000007 1432 9044 64 Yes
Router Priority: 1
Options: V6E---R--
LinkLocal Address: fe80::214:ff:fe77:96ff
Number of Prefix: 1
Prefix Options:
Prefix: 5100::193:213:111:0/112
LSA Key - Rtr:Router Net:Network Inap:InterPrefix Inar:InterRouter
Extn:ASExternal Grp:GroupMembership Typ7:Type7 Link:Link
Iap:IntraPrefix Grc:Grace
Area ID Type LSID Adv Rtr Seq(Hex) Age Cksum Len Sync
0.0.0.200 Link 136 192.168.98.111 80000007 737 fb0b 64 Yes
Router Priority: 1
Options: V6E---R--
LinkLocal Address: fe80::768e:f8ff:fe3e:1800
--More--, next page: Space, next line: Return key, quit: Control-c
NOTE
Portions of this display are truncated for brevity. The purpose of this display is to show all possible elds that might display
rather than to show complete output.
The elds that display depend upon the LSA type as shown in the following.
TABLE 72 OSPFv3 detailed database information
elds
This eld Displays
Router LSA (Type 1) (Rtr) Fields
Capability Bits A bit that indicates the capability of the device. The bit can be set to one of the following:
B - The device is an area border router.
E - The device is an AS boundary router.
V - The device is a virtual link endpoint.
W - The device is a wildcard multicast receiver.
Options A 24-bit eld that enables IPv6 OSPF routers to support the optional capabilities. When set, the
following bits indicate the following:
V6 - The device should be included in IPv6 routing calculations.
E - The device oods AS-external-LSAs as described in RFC 2740.
MC - The device forwards multicast packets as described in RFC 1586.
N - The device handles type 7 LSAs as described in RFC 1584.
Displaying OSPFv3 information
FastIron Ethernet Switch Layer 3 Routing
53-1003627-04 323
