TABLE 75 show ipv6 ospf interface output descriptions (continued)
This eld Displays
State The state of the interface. Possible states include the following:
• DR - The interface is functioning as the Designated Router for
OSPFv3.
• BDR - The interface is functioning as the Backup Designated
Router for OSPFv3.
• Loopback - The interface is functioning as a loopback interface.
• P2P - The interface is functioning as a point-to-point interface.
• Passive - The interface is up but it does not take part in forming
an adjacency.
• Waiting - The interface is trying to determine the identity of the
BDR for the network.
• None - The interface does not take part in the OSPF interface
state machine.
• Down - The interface is unusable. No protocol trac can be sent
or received on such a interface.
• DR other - The interface is a broadcast or NBMA network on
which another router is selected to be the DR.
• Active - The interface sends or receives all the OSPFv3 control
packets, and forms the adjacency.
Transmit delay The amount of time, in seconds, it takes to transmit Link State Updates
packets on the interface.
Priority The priority used when selecting the DR and the BDR. If the priority is 0,
the interface does not participate in the DR and BDR election.
Timer intervals The interval, in seconds, of the hello-interval, dead-interval, and
retransmit-interval timers.
DR The router ID (IPv4 address) of the DR.
BDR The router ID (IPv4 address) of the BDR.
Number of I/F scoped LSAs The number of interface LSAs scoped for a specied area, AS, or link.
DR Election The number of times the DR election occurred.
Delayed LSA Ack The number of the times the interface sent a delayed LSA
acknowledgement.
Neighbor Count The number of neighbors to which the interface is connected.
Adjacent Neighbor Count The number of neighbors with which the interface has formed an active
adjacency.
Neighbor The router ID (IPv4 address) of the neighbor. This eld also identies the
neighbor as a DR or BDR, if appropriate.
Interface statistics The following statistics are provided for the interface:
• Unknown - The number of Unknown packets transmitted and
received by the interface. Also, the total number of bytes
associated with transmitted and received Unknown packets.
• Hello - The number of Hello packets transmitted and received
by the interface. Also, the total number of bytes associated with
transmitted and received Hello packets.
• DbDesc - The number of Database Description packets
transmitted and received by the interface. Also, the total number
of bytes associated with transmitted and received Database
Description packets.
• LSReq - The number of link-state requests transmitted and
received by the interface. Also, the total number of bytes
associated with transmitted and received link-state requests.
Displaying OSPFv3 information
FastIron Ethernet Switch Layer 3 Routing
53-1003627-04 329
