TABLE 88 show ipv6 ospf interface output descriptions
This eld Displays
Authentication This eld shows whether or not authentication is congured. If this eld
says "Not Congured," the IPsec-related elds (bold in example screen
output) are not displayed at all.
KeyRolloverTime The number of seconds between each initiation of a key rollover. This eld
shows the congured and current times.
KeyRolloverState Can be:
Not active: key rollover is not active.
Active phase 1: rollover is in its rst interval.
Active phase 2: rollover is in its second interval.
Current Shows current SPI, authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the current key.
New (Inbound or Outbound) Shows new SPI (if changed), authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the new key.
Old (Inbound or Outbound) Shows old SPI (if changed), authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the old key.
OSPF messages dropped Shows the number of packets dropped because the packets failed
authentication (for any reason).
Displaying IPsec for a virtual link
To display IPsec for a virtual link, run the show ipv6 ospf virtual-link brief or show ipv6 ospf virtual-link command, as the following
examples illustrate.
device# show ipv6 ospf virtual-link brief
Index Transit Area ID Router ID Interface Address State
1 1 10.14.14.14 2001:db8::1:1:1::1 P2P
device# show ipv6 ospf virtual-link
Transit Area ID Router ID Interface Address State
1 10.14.14.14 2001:db8:1:1:1::1 P2P
Timer intervals(sec) :
Hello 10, Hello Jitter 10, Dead 40, Retransmit 5, TransmitDelay 1
DelayedLSAck: 5 times
Authentication: Configured
KeyRolloverTime(sec): Configured: 10 Current: 0
KeyRolloverState: NotActive
Outbound: SPI:100004, ESP, SHA1
Key:1234567890123456789012345678901234567890
Inbound: SPI:100004, ESP, SHA1
Key:1234567890123456789012345678901234567890
Statistics:
Type tx rx tx-byte rx-byte
Unknown 0 0 0 0
Hello 65 65 2600 2596
DbDesc 4 4 2752 2992
LSReq 1 1 232 64
LSUpdate 11 5 1040 1112
LSAck 5 8 560 448
OSPF messages dropped,no authentication: 0
Neighbor: State: Full Address: 2001:db8:44:44::4 Interface: eth 1/2/2
Syntax: show ipv6 ospf virtual-link [brief]
The optional brief keyword limits the display to the Transit, Area ID, Router ID, Interface Address, and State
elds for each link.
Displaying OSPFv3 information
FastIron Ethernet Switch Layer 3 Routing
53-1003627-04 345
