TABLE 87 show ipv6 ospf area output descriptions
This eld Displays
Authentication This eld shows whether or not authentication is congured. If this eld
says "Not Congured," the IPsec-related elds (bold in example screen
output) are not displayed at all.
KeyRolloverTime The number of seconds between each initiation of a key rollover. This eld
shows the congured and current times.
KeyRolloverState Can be:
Not active: key rollover is not active.
Active phase 1: rollover is in its rst interval.
Active phase 2: rollover is in its second interval.
Current Shows current SPI, authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the current key.
New Shows new SPI (if changed), authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the new key.
Old Shows old SPI (if changed), authentication algorithm (currently ESP only),
encryption algorithm (currently SHA1 only), and the old key.
Displaying IPsec for an interface
To see IPsec conguration for a particular interface or all interfaces, use the show ipv6 ospf interface command as in the following
example. IPsec information appears in bold.
device# show ipv6 ospf interface
eth 1/1/3 is down, type BROADCAST
Interface is disabled
eth 1/1/8 is up, type BROADCAST
IPv6 Address:
2001:db8:18:18:18::1/64
2001:db8:18:18::/64
Instance ID 255, Router ID 10.1.1.1
Area ID 1, Cost 1
State BDR, Transmit Delay 1 sec, Priority 1
Timer intervals :
Hello 10, Hello Jitter 10 Dead 40, Retransmit 5
Authentication: Enabled
KeyRolloverTime(sec): Configured: 30 Current: 0
KeyRolloverState: NotActive
Outbound: SPI:121212, ESP, SHA1
Key:1234567890123456789012345678901234567890
Inbound: SPI:121212, ESP, SHA1
Key:1234567890123456789012345678901234567890
DR:10.2.2.2 BDR:10.1.1.1 Number of I/F scoped LSAs is 2
DRElection: 1 times, DelayedLSAck: 83 times
Neighbor Count = 1, Adjacent Neighbor Count= 1
Neighbor:
10.2.2.2 (DR)
Statistics of interface eth 1/1/8:
Type tx rx tx-byte rx-byte
Unknown 0 0 0 0
Hello 1415 1408 56592 56320
DbDesc 3 3 804 804
LSReq 1 1 28 28
LSUpdate 193 121 15616 9720
LSAck 85 109 4840 4924
OSPF messages dropped,no authentication: 0
Syntax: show ipv6 ospf interface [ethernet unit/slot/port | loopback number | tunnel number | ve number]
Displaying OSPFv3 information
FastIron Ethernet Switch Layer 3 Routing
344 53-1003627-04
