Fig. 5-6
Fig. 5-7
Fuser lamp
Fuser roller (HT)
(H): SM3x6 with washe
r
(E): SM3x6 with washe
r
Fuser lamp
Lamp holde
r
(I): SM3x6 with washe
r
(K): FU shoulder screw
(L): BT3x6
(J): ST3x6
with washe
r
(L): BT3x12
Fuser connector FU
Thermistor ASSY FU
Bottom fuser cover FU
