COPYRIGHT
©
1999 CANON INC. CANON GP605/605V REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
6-45
CHAPTER 6 IMAGE FORMATION SYSTEM
Figure 6-501 Construction of the Drum Cleaner Unit
V . DRUM CLEANER UNIT
A. Outline
Volume 3>Chapter 6>V. "Drum Cleaning"
Figure 6-501 shows the construction of the drum cleaner unit.
Pre-exposure lamp
Cleaning blade
Magnet roller
Separation claw
Waste toner feeding screw
M1
Main motor
To Next Page
